Shashank Stainless based in Dubai, UAE is a leading supplier of high-quality stainless steel products. Specializing in providing to the needs of diverse industries. We offer top-notch AWS Class ER316/316L MIG and TIG Filler Welding Wire and Rod designed for superior weldability and corrosion resistance in demanding applications. Our Stainless Steel AWS Class ER316/316L is useful for welding stainless steel offering excellent strength and resistance to oxidation.
AWS Class ER316/316L MIG and TIG Filler Welding Wire and Rod are designed for welding stainless steels. Particularly where high corrosion resistance and durability are required. ER316 is suited for applications exposed to chlorides and corrosive environments. While ER316L offers lower carbon content for improved weldability and resistance to intergranular corrosion. The typical composition includes 16-18% chromium, 10-14% nickel, and 2-3% molybdenum. Enhancing resistance to pitting and crevice corrosion. ER316L is often preferred for welding thinner sections and for applications in the chemical, petrochemical and marine industries ensuring robust and long-lasting welds.
| Classification | AWS A5.9, ER316/316L |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER316/316L MIG & TIG Filler Metal Application & uses |
|
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 1.0-2.5 | 0.30-0.65 | 0.03 | 0.03 | 0.75 |
| Yield, kpsi: | 80 |
| Tensile Strength, kpsi: | 55 |
| Elongation%, min: | 40 |
Contact us to get a quick quote for your requirement.
ER316/316H MIG filler wire provides excellent corrosion resistance and strength, ideal for welding stainless steels in chemical, petrochemical, and marine applications, with high durability in harsh environments.
ER316/316H TIG filler wire ensures superior corrosion resistance and strength for precise welding of stainless steels, suitable for high-temperature environments in industries like chemical processing and aerospace.
ER316/316H TIG filler rod offers excellent resistance to corrosion and high temperatures, ideal for welding and repairing stainless steel components in demanding applications, including chemical and marine industries.
AWS class 316/316L for MIG and TIG welding wire or rod requires careful packing with high standard materials for safe delivery in order to prevent defect and contamination during shipping. Although we always try to go for on-time shipment. We prioritize the satisfaction of our customers through effective transportation options. In this effort all vital information concerning the product is disclosed to the customer through the accompanying data upon delivery, so they may rest assured of the transparency facility.
AWS class ER316/316L MIG and TIG filler welding wires and rods are widely used for stainless steel welding in applications. Requiring high corrosion resistance and excellent weldability. ER316 is ideal for chloride and chemical environments. Making it suitable for industries such as petrochemical, marine, and food processing. ER316L, with its low carbon content, is preferred for welding thin materials and applications where intergranular corrosion resistance is critical Both fillers are used in tanks, pipes, pressure vessels and other manufacturing and and repair to ensure strong, durable welds that can withstand harsh and damaging conditions.
